KEY FEATURES
- High capacity mixed bed ion exchange resin
- Consists of a mixture of a gel, Type I strong base anion resin and a gel strong acid cation resin for direct purification of water
- High Quality & Cost-Effective
- The conductivity is 0.1us/cm max
SPECIFICATION
Applications
Pure PMB101-2 is suitable for use in regenerable or non-regenerable cartridges, for deionization with high silica removal efficiency and refine water for electrical home applications.
Technical characteristics of the media
- Polymer Matrix Structure – Gel Polystyrene cross linked with DVB
- Functional Group:
– Cation – RSO3–H+
– Anion – R4N+OH–
- Ionic Form, as shipped – H+ / OH+
- Physical Form And Appearance – Clear Spherical Beads
- Sphericity – 95% min
- Screen Size Range (U.S. Standard Screen) – 16-50 mesh, wet
- Particle Size Range – +1.2 mm < 5%, -0.3 mm < 1%
- Volume Ratio (as shipped)
– Cation – 40% PC003H
– Anion – 60% PA101OH
- Total Exchange Capacity,
– Cation (in sodium form) – 2.0 eq/l min.
– Cation (in H form) – 1.9 eq/l min.
– Anion (in chloride form) – 1.3 eq/l min.
– Anion (in OH form) – 1.0 eq/l min
- pH Range – 0-14
- Maximum operating temperature – 120ºC
- Minimum Bed Dept – 0.7 m (2.3 ft)
