Mixed bed ion exchange resin PMB101-2

7.45  available on subscription

Neturime

KEY FEATURES

  • High capacity mixed bed ion exchange resin
  • Consists of a mixture of a gel, Type I strong base anion resin and a gel strong acid cation resin for direct purification of water
  • High Quality & Cost-Effective
  • The conductivity is 0.1us/cm max

SPECIFICATION

Applications

Pure PMB101-2 is suitable for use in regenerable or non-regenerable cartridges, for deionization with high silica removal efficiency and refine water for electrical home applications.

Technical characteristics of the media

  • Polymer Matrix Structure – Gel Polystyrene cross linked with DVB
  • Functional Group:

            – Cation – RSO3H+

            – Anion – R4N+OH

  • Ionic Form, as shipped – H+ / OH+
  • Physical Form And Appearance – Clear Spherical Beads
  • Sphericity – 95% min
  • Screen Size Range (U.S. Standard Screen) – 16-50 mesh, wet
  • Particle Size Range – +1.2 mm < 5%, -0.3 mm < 1%
  • Volume Ratio (as shipped)

           – Cation – 40% PC003H

           – Anion – 60% PA101OH

  • Total Exchange Capacity,

           – Cation (in sodium form) – 2.0 eq/l min.

           – Cation (in H form) – 1.9 eq/l min.

           – Anion (in chloride form) – 1.3 eq/l min.

           – Anion (in OH form) – 1.0 eq/l min

  • pH Range – 0-14
  • Maximum operating temperature – 120ºC
  • Minimum Bed Dept – 0.7 m (2.3 ft)
